Bored Pile Hydraulic Casing Oscillator Large Holding Force

Beijing jiayou xincheng industry and trade co. LTD
Contact Now
    Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers

    Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers
    • Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers
    • Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers
    • Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers
    • Buy cheap Bored Pile Hydraulic Casing Oscillator Large Holding Force from wholesalers

    Bored Pile Hydraulic Casing Oscillator Large Holding Force

    Ask Lasest Price
    Brand Name : JYXC
    Model Number : APFCZX/APFXWX
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : Subject to the contract
    Delivery Time : Subject to the contract
    • Product Details
    • Company Profile

    Bored Pile Hydraulic Casing Oscillator Large Holding Force

    APFCZX/APFXWX Series Casing Oscillators:


    APFCZX and APFXWX Casing Oscillators are two series we design for different pile construction applications:

    • APFCZX series, or "Long" type, are usually mounted to a crane and ideal for boring large diameter, deep piling shafts in variable or indeterminate soil conditions where there is risk of collapse. All models of this series are available for casing diameters from 1000 to 3000mm.
    • APFXWX series, or "Short" type, are usually mounted to a rotary drilling rig and ideal for boring piling shafts in variable or indeterminate soil conditions where there is risk of collapse. All models of this series are available for casing diameters from 1000 to 2500mm.

    Features:

    • 3-segment clamping collar can make casing tube automatically align to the center, with large clamping force.
    • Computer simulation is well applied in mechanical&structural optimization design for variant construction conditions, hence effectively avoiding the possibilities of motion arc interference and hang&beat in working process.
    • Either electric or diesel power pack is available as per customer's requirements.
    • Optional manual and remote control operation mode, which are easily to switch between each other.

    Applicable stratum:

    Applicable for all strata that suit rotary drilling rig, especially for those complex strata in which are difficult to make wall protection, such as pebble, silt, quicksand, fragmented, karst cave, backfill, swamp, lake, river etc.


    Bored Pile Hydraulic Casing Oscillator Large Holding Force


    Bored Pile Hydraulic Casing Oscillator Large Holding Force


    Bored Pile Hydraulic Casing Oscillator Large Holding Force

    Bored Pile Hydraulic Casing Oscillator Large Holding Force




    Packaging & Delivery:

    Quantity(Sets):≥1
